24v 30w triac & 0 10v dimmable led light strip driver power supply ip20
This plastic casing constant voltage LED driver 30W has PFC function, working efficiency up to 80%, complies with global safety lighting regulations, UL certified, mainly sold to North America, with 7-year warranty
Specification
model
SMT-012-030VTD
SMT-024-030VTD
Output
DC Voltage
12V
24V
Voltage Tolerance
±0.5V
±0.5V
Voltage Regulation
±0.5%
Rated current
2.50A
1.250A
Load Regulation
±1%
Rated power
30W
30W
Input
Voltage Range
100-277V AC
THD(Typ. ) @ full load
<20%@120VAC &277VAC
Frequency Range
47～63HZ
Power Factor ( Typ.）
0.99@120VAC 0.98@277VAC
0.99@120VAC 0.95@277VAC
Full Load Efficiency（Typ.）
79%@120VAC 80%@277VAC
79%@120VAC 80%@277VAC
AC Current（Typ.）
0.5A
Inrush Current （Typ.）
7A, 50%, 420us @120VAC; 12A, 50% , 480us @277VAC
Leakage current
<0.5mA
Protection
Over temperature
100℃±10℃ shut down o/p voltage, automatically recover after cooling.
Short Circuit
shut down o/p voltage, re-power on to recover after fault condition removed
Over Loading
≤120% Hiccup mode,recovers automatically after fault condition is removed
Environment
Working TEMP.
-40~+60℃ (see below derating curve)
Working Humidity
20 - 95%RH,non-condensing
Storage TEM.,Humidity
-40 - +80℃,10 - 95%RH
TEMP.coefficient
±0.03%/℃(0 - 50℃)
Vibration
10～500Hz, 2G 10min./1 cycle,period for 60min. each along X,Y,Z axes
Safety&EMC
Safety standards
UL8750+UL1310 , CAN/CSA-C22.2 No.250.13
Withstand voltage
I/P-O/P:1.88KVac
Isolation resistance
I/P-O/P:100MΩ/500VDC/25℃/70%RH
EMC EMISSION
FCC 47 CFR Part 15 ,Subpart B
Others
Weight
About 0.25Kg
Size
155*54*20mm (L*W*H)
packing
Carton size: 350*240*130mm , 40PCS/CTN（L*W*H）
Notes
1. All parameters NOT specially mentioned are measured at 120VAC input , rated load and 25℃of ambient temperature.
2. Tolerance: includes set up tolerance, line regulation and load regulation .
3. The power supply is considered as a component that will be operated in combination with final Equipment. Since EMC performance will be affected by the complete installation, the final equipment manufactures must be-qualify EMC Directive on the complete installation again.
 |
 |
 |
 |
Mechanical Specification
Input wire Black and White to be connected to AC L and N ,Green wire go ground,
Output wire Red to LED Positive side (+) , Black to LED Negative side (-).
Dimming cable DIM (+) Purple to 0/1-10V dimmer signal(+ ),DIM (-) Grey to 0/1-10V dimmer signal (-)
Please make sure your connect these correctly otherwise your product will not function correctly and could be damaged.
Dimming operation
Compatible LED strip lighting
When it comes to dimmable electronic transformer, they are the perfect lighting solution for anyone who's looking for an easy and quick installation while keeping the high quality lighting that Flexfire LEDs is known for.
