Smarts Electronics constant voltage 24v led strip power supply is reliable, long-lasting and versatile. With 2&3 years warranty, this driver can be used to run back-lit ad signs, architecture lighting, landscape lighting and more.
|
Details for led driver 15w:
|
Label
|
 |
 |
|
Features IP44 design for indoor installations Protections:Short circuit/Overload/Over temperature Cooling by free air convection 100% full load burn-in test Suitable for LED lighting Products through CE,RoHS Certification 2 years warranty |
SPECIFICAION for 12v 18w led driver
| MODEL | SMT-012-015VWP | SMT-024-015VWP | |||
| OUTPUT | DC VOLTAGE | 12V | 24V | ||
| RATED CURRENT | 1.25Amp | 0.625Amp | |||
| VOLTAGE RANGE |
|
|
|
|
|
| RATED POWER | 15Watt | ||||
| RIPPLE&NOISE(max) | 300mV | ||||
| VOLTAGE TOLERANCE | ±5% | ||||
| LINE REGULATION | ±1% | ||||
| LOAD REGULATION | ±2% | ||||
| INPUT | VOLTAGE RANGE | 100-240VAC | |||
| FREQUENCY RANGE | 47-63Hz | ||||
| POWER FACTOR(Typ.) |
|
|
|
|
|
| EFFICIENCY(Typ.) | ﹥83% | ||||
| AC CURRENT(Typ.) | 0.17A/110VAC, 0.0.86/220VAC | ||||
| PROTECTION | SHORT CIRCUIT | Protection type:recovers automatically after condition is removed | |||
| OVER CURRENT | overload protected@145-160% above peak rating | ||||
| OVER LOAD | 2.3A | 1.2A |
|
|
|
| ENVIRONMENT | WORKING TEMP. | -10～+50℃ (Refer to output load derating curve) | |||
| WORKING HUMIDITY | 20～99% RH non-condensing | ||||
| STORAGE TEMP.,HUMIDITY | -40～+80℃,10～99%RH | ||||
| SAFETY&EMC | SAFETY STANDARDS | EN61347-1;EN61347-2-13;CE /ROHS approval | |||
| WITHSTAND VOLTAGE | I/P-O/P:2KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC | ||||
| EMC Test Standards | EN55015;EN61000-3-2;EN61000-3-3; | ||||
| EN61547;EN61000-4-2,3,4,5,6,8,11; | |||||
 |
 |
 |
 |
Product size
Other
Dimention:
127.5*50*12mm
Carton quantity:
50pcs/ctn
Carton size:
309*279*176mm
Net weight:
60g/pcs
