24v 80w LED strips triac dimmable electronic transformer

24v 80w LED strips triac dimmable electronic transformer

 Product parameters

model		SMT-012-080VT	SMT-024-080VT
Output	DC Voltage	12V	24V
	Voltage Accuracy	±0.5V	±0.5V
	Rated current	6.66A	3.33A
	Rated power	80W
Input	Voltage Range	100~130V AC/170～265V AC
	Frequency Range	47～63HZ
	Power Factor ( Typ.）	PF≧0.70/110V,PF≧0.70/170V,PF≧0.70/220V,PF≧0.70/265V
	Full Load Efficiency（Typ.）	>84%	>84%
	AC Current（Typ.）	1.24A/110VAC  0.80A/170VAC  0.62A/220VAC  0.51A/265VAC
	Leakage current	﹤0.25mA/110V/220VAC
Protection	Short Circuit	Hiccup mode, recovers automatically after fault condition is removed.
	Over voltage	≦140VAC(90~135V) , ≦270VAC(170~265V)
Environment	Working TEMP.	-40～+60℃
	Working Humidity	20～90%RH,non-condensing
	Storage TEM.,Humidity	-40～+80℃，10～95%RH
	TEMP.coefficient	±0.03%/℃（0～50℃）
	Vibration	10～500Hz，2G 10min./1 cycle，period for 60min. each along X,Y,Z  axes
Safety&EMC	Safety standards	EN-60950-1, EN61347-1/-2/-13
	Withstand voltage	I/P-O/P:3.75KVAC
	Isolation resistance	I/P-O/P：100MΩ/500VDC/25℃/70%RH
	EMC EMISSION	Compliance toEN55015,EN61000-3-2 (≧50%load)
	EMC IMMUNITY	Compliance to EN55015; EN61000-4-2,3,4,5,6,8,11,EN61547 Alight industry level （surge4KV）
Others	Weight	0.99Kg
	Size	210*68.5*43mm（L*W*H）
	packing	324*298*176mm
	Notes	1. All parameters NOT specially mentioned are measured at 110V/230VAC input , rated load and 25℃of ambient temperature. 2. Ripple& noise are measured at 20MHz of bandwidth by using a 12”twisted  pair-wire terminated with a 0.1uf &47uf parallel capacitor. 3.Tolerance:includes set us tolerance,line regulation and load regulation .
Label

 Specifications

• Efficiency > 85%
• PF>0.95
• Working mode: constant voltage
• Dimming mode: traic dimmable
• Case material: aluminium housing
• produt cord:connecting terminal(IP20) / 18AWG*20CM
• 3 years warranty (We promise to replace new ones to you if there is any defective happen during the warranty period)

 Features

• High efficiency,save energy ,protected environment.
• High stability and low ripple, increase light efficiency and decrease light attenuation.
• Meet to safety standard and EMC
• Assure LED stability long lift and light efficiency by constant voltage.
• Protections:Short circuit/Overload/Over temperature
• Cooling by free air convection
• 100% full load burn-in test.
• Suitable for LED lighting

 Safety

• Safety Standards : IEC 61347 –2–11 , EN55015,EN61000
• Withstand Voltage : I/P-O/P: 3000KVAC
• Isolation Resistance : I/P-O/P:100M Ohms/500VDC

 Application

• Indoor LED illuminating lights
• LED Neon, LED urban Decoration
• LED Lighting Advertising,LED Display
• Safety Protection Apparatus
• Telecommunications, Networks
• Vehicle Lights, Controller Panels
