ip20 smps enclosure 150w 12v 12.5amp
Product Description
Product parameters:
SMT-012-150SA
SMT-024-150SA
SMT-036-150SA
SMT-048-150SA
DC output voltage
12V
24V
36V
48V
Output Voltage Tolerance (Note 2)
± 2%
± 3%
±2%
± 2%
Rated output current
12.5A
6.25A
4.17A
3.125A
Output Current Range
2-12.5A
3-6.25A
1-4.17A
0.8-3.125A
Ripple and noise (Note 3)
60mVp-p
120mVp-p
60mVp-p
150mVp-p
Into the line of stability (Note 4)
± 0.5%
± 1%
± 0.5%
± 1%
Load stability (Note 5)
± 0.5%
± 5%
± 0.5%
± 6%
DC output power
150W
Efficiency
>82%
>81%
>83%
>82%
DC voltage adjustable range
Input Voltage Range
100 ~ 265VAC Selected by switch 47 ~ 63Hz
Input Current
2.5A /115V ,1.25A/ 230V
Inrush Current
Cold-start Current 35A
Leakage
<3.5mA/240VAC
Overload
105% ~ 150% Type: pulsing hiccup shutdown Reset:auto recovery
Over Voltage Protection
3.125V ~ 12.5V
Temperature Protection
------ ------
Temperature Coefficient
± 0.03%/°C (0 ~ 50°C) ON +5V
Start, rise, hold time
200ms,50ms,20ms
Earthquake resistance
10 ~ 500Hz, 2G 10min / 1 cycle, a total of 60 minutes, each axis
Pressure of
Between input and output: 1.5KvAC, input and shell: 1.5KvAC ,output and shell: 0.5KvAC
Isolation Resistance
Input and output,input and shell, shell and output: 500VDC/100M Ohms
Temperature, humidity
-10°C ~ + 60°C ,20% ~ 90%RH
Storage temperature, temperature
-20°C ~ + 85°C,10% ~ 95%RH
Dimensions
199*110*50mm
Weight
0.72Kg/pcs
Safety Standards
TUV EN60950 ,EN61347-1, TUV EN60950
EMC Standards
IEC8012-3,4, IEC555-2 IEC8012-3, 4, IEC555-2
Notes:
1 The above parameters test conditions are: 230VAC input, rated load, 25 °C 70% RH. Humidity.
2 Tolerance: includes set up tolerance, line stability, load stability (Note 5).
3 The ripple test: 20MHz with A12 "twisted pair, interrupted with 0.1uF & 47uF capacitor short-circuit.
4 Into the line voltage stability test: full load into the line of the minimum voltage to maximum voltage.
5 Load stability test: the load from 0% to 100%, and other output at 60% rated load.
6 The output of up to maximum current, but the overall load can not exceed the maximum output power.
-
CE,ROHS approval
-
2 years warranty (We promise to replace new ones to you if there is any defective happen during the warranty period)
Features:
-
Constant voltage design with high accuracy.
-
International wide input voltage.
-
output voltage 5v/12v/24v/36v/48v selectable.
-
Wattage: 15w-600w.
-
High efficiency, save energy, protected environment.
-
High stability and low ripple, increase light efficiency and decrease light attenuation.
-
Meet to safety standard and EMC.
-
Assure LED stability long lift and light efficiency by constant voltage.
-
Overcurrent, overvoltage, overheat, short curcuit protection:Auto-recovery
-
Start,raise,stable time: 500ms,30ms,40ms/230VAC,500ms,30ms,16ms/115VAC
-
Cooling by free air convection.
-
100% full load burn-in test.
-
Brand electrotronic components.
-
ROHS material.
-
Well match with LED guardrail lamp, Flood light, light word, street lamp etc, For LEDs series-parallel.
Application:
-
Indoor LED illuminating lights
-
LED Neon, LED urban Decoration
-
LED Lighting Advertising,LED Display
-
Safety Protection Apparatus, Telecommunications
Packaging & Shipping
Packing
N.W./pcs
G.W/ctn
Qty/ctn
Carton Size( m³)
ip20 smps enclosure 150w 12v 12.5amp
720g/pcs
23kg/ctn
30pcs
0.0318 m³
Packing:
Company Information
Quanzhou Smarts Electronic & Technology Co.,Ltd (SMARTS INDUSTRIAL (HOLDING) CO LTD) was founded in 1998. The company is located in a developed economy, abundant resources, beautiful scenery of Quanzhou city Licheng district town pontoon, the company has an area of 2000 square meters, production workshop, warehouse, office, living facilities complete with. With the development of society, human increasing awareness of "green energy, environmental protection, save energy" becomes...View this Supplier's Website
Product parameters:
|
SMT-012-150SA |
SMT-024-150SA |
SMT-036-150SA |
SMT-048-150SA |
DC output voltage |
12V |
24V |
36V |
48V |
Output Voltage Tolerance (Note 2) |
± 2% |
± 3% |
±2% |
± 2% |
Rated output current |
12.5A |
6.25A |
4.17A |
3.125A |
Output Current Range |
2-12.5A |
3-6.25A |
1-4.17A |
0.8-3.125A |
Ripple and noise (Note 3) |
60mVp-p |
120mVp-p |
60mVp-p |
150mVp-p |
Into the line of stability (Note 4) |
± 0.5% |
± 1% |
± 0.5% |
± 1% |
Load stability (Note 5) |
± 0.5% |
± 5% |
± 0.5% |
± 6% |
DC output power |
150W |
|||
Efficiency |
>82% |
>81% |
>83% |
>82% |
DC voltage adjustable range |
|
|
||
Input Voltage Range |
100 ~ 265VAC Selected by switch 47 ~ 63Hz |
|||
Input Current |
2.5A /115V ,1.25A/ 230V |
|||
Inrush Current |
Cold-start Current 35A |
|||
Leakage |
<3.5mA/240VAC |
|||
Overload |
105% ~ 150% Type: pulsing hiccup shutdown Reset:auto recovery |
|||
Over Voltage Protection |
3.125V ~ 12.5V |
|||
Temperature Protection |
------ ------ |
|||
Temperature Coefficient |
± 0.03%/°C (0 ~ 50°C) ON +5V |
|||
Start, rise, hold time |
200ms,50ms,20ms |
|||
Earthquake resistance |
10 ~ 500Hz, 2G 10min / 1 cycle, a total of 60 minutes, each axis |
|||
Pressure of |
Between input and output: 1.5KvAC, input and shell: 1.5KvAC ,output and shell: 0.5KvAC |
|||
Isolation Resistance |
Input and output,input and shell, shell and output: 500VDC/100M Ohms |
|||
Temperature, humidity |
-10°C ~ + 60°C ,20% ~ 90%RH |
|||
Storage temperature, temperature |
-20°C ~ + 85°C,10% ~ 95%RH |
|||
Dimensions |
199*110*50mm |
|||
Weight |
0.72Kg/pcs |
|||
Safety Standards |
TUV EN60950 ,EN61347-1, TUV EN60950 |
|||
EMC Standards |
IEC8012-3,4, IEC555-2 IEC8012-3, 4, IEC555-2 |
|||
Notes:
1 The above parameters test conditions are: 230VAC input, rated load, 25 °C 70% RH. Humidity. |
- CE,ROHS approval
- 2 years warranty (We promise to replace new ones to you if there is any defective happen during the warranty period)
Features:
- Constant voltage design with high accuracy.
- International wide input voltage.
- output voltage 5v/12v/24v/36v/48v selectable.
- Wattage: 15w-600w.
- High efficiency, save energy, protected environment.
- High stability and low ripple, increase light efficiency and decrease light attenuation.
- Meet to safety standard and EMC.
- Assure LED stability long lift and light efficiency by constant voltage.
- Overcurrent, overvoltage, overheat, short curcuit protection:Auto-recovery
- Start,raise,stable time: 500ms,30ms,40ms/230VAC,500ms,30ms,16ms/115VAC
- Cooling by free air convection.
- 100% full load burn-in test.
- Brand electrotronic components.
- ROHS material.
- Well match with LED guardrail lamp, Flood light, light word, street lamp etc, For LEDs series-parallel.
Application:
- Indoor LED illuminating lights
- LED Neon, LED urban Decoration
- LED Lighting Advertising,LED Display
- Safety Protection Apparatus, Telecommunications
Packing | |||||||
N.W./pcs | G.W/ctn | Qty/ctn | Carton Size( m³) | ||||
ip20 smps enclosure 150w 12v 12.5amp | |||||||
720g/pcs | 23kg/ctn | 30pcs | 0.0318 m³ | ||||
Packing:
Our team
Factory & Equipments view
CE ROHS Certification
Our Services
-
We are CE audited LED drivers/power supplies enterprise in China
-
Alibaba assessed 6 years Gold Supplier and more than 10 years LED industrial experience. It will guarantee your order 100% safe
-
Price is negotiable if you have large quantity demand
-
100% QC inspection Before Shipping
-
Best Quality & Best Service with Competitive price
-
Shipping will be the most economical for you and freight cost is informed in advance
-
consideration.decision for the shipping terms will be made according to your requirements
-
We have our engineer team, if you have any question about your LED applications, let us know freely, we will give you the best solution
-
Our trade manager is online 12 hours. and we will reply your inquiry within 8 hours
-
OEM design & OEM packing welcome
-
Samples will be ready within 7 working days
FAQ
Q1. What's type power supply do you have?
A1: We specialized in constant voltage & current LED drivers, 0-10v/triac/DALI
dimmable led drivers, enclosure power suppliers, power adapters.
Q2. What's shipping mode can we choose?
A2:1.FedEx/DHL/UPS/TNT/Express for samples;
2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;
3. Customers specifying freight forwarders or negotiable shipping methods!
Q3. What's the MOQ?
A3: Our MOQ is 500pcs, but we accept your trail order/small order, no problem.
Q4. What can you do if the product is broken?
A4: We promise to replace new ones to you if there is any defective happen during
the warranty period, but we need pictures or video to prove the defective comes
from our quality problem.
Q5. How about the protection of product?
A5: Most of our products have protection of short-circuit, overload, over voltage,
over current and reserve polarity. About the specific product, please consult
our sales stuff.
Q6. How about the transportation?
A6: For small order,express will be best.And for bulk order,sea ship way is best but
take much time. For urgent orders,we suggest via air to airport plus our ship partner
send to your door. We will cooperate with your choice.
Q7. What's the Payment do you have?
A7: To assure you the maximum comfort and satisfaction, Currently, you can pay via
T/T, L/C, WESTERN UNION, PAYPAL. More payment options will be added in the
near future.
