12v 72w IP20 power supply

12v 72w IP20 power supply

Product Description

Product parameters:

Model		SMT-005-72SA	SMT-012-72SA	SMT-024-72SA	SMT-036-72SA	SMT-048-72SA
output	DC voltage	5V	12V	24V	36V	48V
	Voltage tolerance	±2%	±1%	±1%	±1%	±1%
	Rated current	14.4A	6A	3A	2A	1.5A
	Current range	0~14.4A	0~6A	0~3A	0~2A	0~1.5A
	Rated power	72W	72W	72W	72W	72W
	Ripple&noise	100mvp- p	150mvp-p	150mvp-p	150mvp-p	150mvp-p
	DCvoltage ADJ.range	±10%	±10%	±10%	±10%	±10%
input	Voltage range	100~240Vdc
	frequency	47~63HZ
	efficiency	83%	83%	83%	83%	83%
	Inrush current	Cold start current 18A/115VAC,36A/230VAC
	Leakage current	< 1mA/240VAC
	protection	overload	Rated output power115%~150% start over load protection
protection type:                                           cutoff output,recovery after restart power
Over voltage	6.8~8.2V		30.6~33.2V	33.2~35.6V	54.8~56.6V
	protection type:hiccup mode,auto-recovery after fault condition is removed
environment	Working temp,humidity	-10°C~+60°C,20%~90%RH
	Storagetemp,humidity	-20°C~+85°C,10%~95%RH non-condensing
	Withstand vibration	10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes
safety	Withstand voltage	I/P-O/P:2.0KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
	Isolated resistance	I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC
Fitstandard
	EMC standard	Comply with EN55022,CLASSA
others	Dimension	112*88*34mm  (L*W*H)
	Weight/packing	0.5kg/30pcs/15kg/0.335m³
note	1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation



Features:

• Constant voltage design with high accuracy.
• International wide input voltage.
• output voltage 5v/12v/24v/36v/48v selectable.
• Wattage: 15w-600w.
• High efficiency, save energy, protected environment.
• High stability and low ripple, increase light efficiency and decrease light attenuation.
• Meet to safety standard and EMC.
• Assure LED stability long lift and light efficiency by constant voltage.
• Overcurrent, overvoltage, overheat, short curcuit protection:Auto-recovery
• Start,raise,stable time:  500ms,30ms,40ms/230VAC,500ms,30ms,16ms/115VAC
• Cooling by free air convection.
• 100% full load burn-in test.
• Brand electrotronic components.
• ROHS material.
• Well match with LED guardrail lamp, Flood light, light word, street lamp etc, For LEDs series-parallel.

Environment :

• Working Temperature : -25 ~ +50°C
• Working Humidity : 20 ~ 90% RH non-condensing
• Storage Temp. , Humidity : -40 ~ +80°C , 10 ~ 95% RH
• TEMP. Coefficient : ±0.03%/°C (0 ~ 50°C)
• Vibration : 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

Safety :

• Safety Standards : IEC 61347 –2–11 , IEC 61347 –1 , IEC 60529 , IP67 approved
• Withstand Voltage : I/P-O/P: 3000KVAC
• Isolation Resistance : I/P-O/P:100M Ohms/500VDC

Applications:

• indoor LED illuminating lights, LED Neon
• LED urban Decoration,LED Lighting Advertising
• LED Display, Safety Protection Apparatus
• Telecommunications, Networks
• Vehicle Lights, Controller Panels

Packaging & Shipping

Packing
N.W./pcs		G.W/ctn		Qty/ctn		Carton Size( m³)
12v 72w IP20 power supply
500g/pcs		13.5kg/ctn		30pcs		0.0318 m³



 Packing:
