400w cctv cameras switch mode power supply 12v

400w cctv cameras switch mode power supply 12v

Product Description

Model		SMT-005-400SA	SMT-012-   400SA	SMT-024-  400SA	SMT-036-  400SA	SMT-048- 400SA
output	DC voltage	5V	12V	24V	36V	48V
	Voltage tolerance	±2%	±1%	±1%	±1%	±1%
	Rated current	80A	33.33A	16.67A	11.11A	8.33A
	Current range	0~80A	0~33.33A	0~16.67A	0~11.11A	0~8.33A
	Rated power	400W	400W	400W	400W	400W
	Ripple&noise	100mvp-p	150mvp-p	150mvp-p	150mvp-p	150mvp-p
	DCvoltage ADJ.range	± 10%	±10%	±10%	±10%	±10%
input	Voltage range	100~240Vdc
	frequency	47~63HZ
	AC current	3.2A/115VAC,1.6A/230VAC
	efficiency	83%	83%	83%	83%	83%
	Inrush current	Cold start current 18A/115VAC,36A/230VAC
	Leakage current	< 1mA/240VAC
protection	overload	Rated output power115%~150% start over load protection
		protection type:cutoff output,recovery after restart power
	Over voltage	6.8~8.2V	15.6~17.8V	18.6~20.8V	30.6~33.2V	33.2~35.6V
		protection type:hiccup mode,auto-recovery after fault condition is removed
	-----	-----
		-----
environment	Working temp,humidity	-10°C~+60°C,20%~90%RH
	Storagetemp,humidity	-20°C~+85°C,10%~95%RH non-condensing
	Withstand vibration	10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes
safety	Withstand voltage	I/P-O/P:2.0KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
	Isolated resistance	I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC



Features:

• High efficiency,save energy ,protected environment.
• High stability and low ripple, increase light efficiency and decrease light attenuation.
• Meet to safety standard and EMC
• Assure LED stability long lift and light efficiency by constant voltage.
• Integrity protection,over loading, over voltage ,over current.
• Protections:Short circuit/Overload/Over temperature
• Cooling by free air convection
• 100% full load burn-in test.
• Suitable for LED lighting

Environment :

• Working Temperature : -25 ~ +50°C
• Working Humidity : 20 ~ 90% RH non-condensing
• Storage Temp. , Humidity : -40 ~ +80°C , 10 ~ 95% RH
• TEMP. Coefficient : ±0.03%/°C (0 ~ 50°C)
• Vibration : 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

Safety :

• Safety Standards : IEC 61347 –2–11 , IEC 61347 –1 , IEC 60529 , IP67 approved
• Withstand Voltage : I/P-O/P: 3000KVAC
• Isolation Resistance : I/P-O/P:100M Ohms/500VDC

Application:

• Indoor LED illuminating lights
• LED Neon, LED urban Decoration
• LED Lighting Advertising,LED Display
• Safety Protection Apparatus
• Telecommunications, Networks
• Vehicle Lights, Controller Panels

Packaging & Shipping

Company Information

Quanzhou Smarts Electronic & Technology Co.,Ltd (SMARTS INDUSTRIAL (HOLDING) CO LTD) was founded in 1998. The company is located in a developed economy, abundant resources, beautiful scenery of Quanzhou city Licheng district town pontoon, the company has an area of 2000 square meters, production workshop, warehouse, office, living facilities complete with. With the development of society, human increasing awareness of "green energy, environmental protection, save energy" becomes...View this Supplier's Website

Our team



Factory & Equipments view





 CE ROHS Certification



Our Services

• We are ETL CE audited LED drivers/power supplies enterprise in China
• Alibaba assessed 6 years Gold Supplier and more than 10 years LED industrial  experience. It will guarantee your order 100% safe
• Price is negotiable if you have large quantity demand
• 100% QC inspection Before Shipping
• Best Quality & Best Service with Competitive price
• Shipping will be the most economical for you and freight cost is informed in advance
• consideration.decision for the shipping terms will be made according to your requirements
• We have our engineer team, if you have any question about your LED applications, let  us know freely, we will give you the best solution
• Our trade manager is online 12 hours. and we will reply your inquiry within 8 hours
• OEM design & OEM packing welcome
• Samples will be ready within 7 working days

FAQ

Q1. What's type power supply do you have?

A1: We specialized in constant voltage & current LED drivers, 0-10v/triac/DALI

       dimmable led drivers, enclosure power suppliers, power adapters.



Q2. What's shipping mode can we choose?

A2:1.FedEx/DHL/UPS/TNT/Express for samples;

      2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;

      3. Customers specifying freight forwarders or negotiable shipping methods!



Q3. What's the MOQ?

A3: Our MOQ is 500pcs, but we accept your trail order/small order, no problem.



Q4. What can you do if the product is broken?

A4: We promise to replace new ones to you if there is any defective happen during

      the warranty period, but we need pictures or video to prove the defective comes

      from our quality problem.



Q5. How about the protection of product?

A5: Most of our products have protection of short-circuit, overload, over voltage,

       over current and reserve polarity. About the specific product, please consult

       our sales stuff.



Q6. How about the transportation?

A6: For small order,express will be best.And for bulk order,sea ship way is best but

       take much time. For urgent orders,we suggest via air to airport plus our ship partner

       send to your door. We will cooperate with your choice.



Q7. What's the Payment do you have?

A7: To assure you the maximum comfort and satisfaction, Currently, you can pay via

        T/T, L/C, WESTERN UNION, PAYPAL. More payment options will be added in the

        near future.
