24v 72w enclosure power supply smps
24v 72w enclosure power supply smps is AC input power suitable for the world, 2 years warranty
Features of 24v 72w enclosure power supply
- Competitived price and high reliability
- 105 °C Output capacitor
- AC input power suitable for the world
- High efficiency and low operation temperature
- Soft-start current can reduce the AC input impact effect
- With short-circuit and overload protection
- Compact size, light weight
- 100% full-load burn-in test
- Installed with EMI filter, minimum wave
- 2 years warranty
Applications of smps
Our products are widely used in various industries, such as
- indoor LED illuminating lights,
- LED Neon,
- LED urban Decoration
- LED Lighting Advertising,
- LED Display,
- Safety Protection Apparatus,
- Telecommunications,
- Networks,
- Vehicle Lights, Controller Panels, etc.
parameter of enclosure power supply
|
Model |
SMT-005-072SA |
SMT-012- 072SA |
SMT-024- 072SA |
SMT-036- 072SA |
SMT-048- 072SA |
|
|
output |
DC voltage |
5V |
12V |
24V |
36V |
48V |
|
Voltage tolerance |
±2% |
±1% |
±1% |
±1% |
±1% |
|
|
Rated current |
14.4A |
6A |
3A |
2A |
1.5A |
|
|
Current range |
0~14.4A |
0~6A |
0~3A |
0~2A |
0~1.5A |
|
|
Rated power |
72W |
72W |
72W |
72W |
72W |
|
|
Ripple&noise |
100mvp-p |
150mvp-p |
150mvp-p |
150mvp-p |
150mvp-p |
|
|
DCvoltage ADJ.range |
± 10% |
±10% |
±10% |
±10% |
±10% |
|
|
input |
Voltage range |
100~240Vdc |
||||
|
frequency |
47~63HZ |
|||||
|
AC current |
3.2A/115VAC,1.6A/230VAC |
|||||
|
efficiency |
83% |
83% |
83% |
83% |
83% |
|
|
Inrush current |
Cold start current 18A/115VAC,36A/230VAC |
|||||
|
Leakage current |
< 1mA/240VAC |
|||||
|
protection |
overload |
Rated output power115%~150% start over load protection |
||||
|
protection type:cutoff output,recovery after restart power |
||||||
|
Over voltage |
6.8~8.2V |
15.6~17.8V |
18.6~20.8V |
30.6~33.2V |
33.2~35.6V |
|
|
protection type:hiccup mode,auto-recovery after fault condition is removed |
||||||
|
----- |
----- |
|||||
|
----- |
||||||
|
environment |
Working temp,humidity |
-10°C~+60°C,20%~90%RH |
||||
|
Storagetemp,humidity |
-20°C~+85°C,10%~95%RH non-condensing |
|||||
|
Withstand vibration |
10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes |
|||||
|
safety |
Withstand voltage |
I/P-O/P:2.0KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC |
||||
|
Isolated resistance |
I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC |
|||||
