12v 60w enclosure power supply
Product Description
Model
SMT-005-060SA
SMT-012-060SA
SMT-024-060SA
SMT-036-060SA
output
DC voltage
5V
12V
24V
36V
Voltage tolerance
±2%
±1%
±1%
±1%
Rated current
12A
5A
2.5A
1.67A
Current range
0~12A
0~5A
0~2.5A
0~1.67A
Rated power
60W
60W
60W
60W
Ripple&noise
100mvp-p
150mvp-p
150mvp-p
150mvp-p
DCvoltage ADJ.range
± 10%
±10%
±10%
±10%
input
Voltage range
100~240Vdc
frequency
47~63HZ
AC current
3.2A/115VAC,1.6A/230VAC
efficiency
83%
83%
83%
83%
Inrush current
Cold start current 18A/115VAC,36A/230VAC
Leakage current
< 1mA/240VAC
protection
overload
Rated output power115%~150% start over
load protection
protection type:cutoff output,recovery after
restart power
Over voltage
6.8~8.2V
15.6~17.8V
18.6~20.8V
30.6~33.2V
protection type:hiccup mode,auto-recovery
after fault condition is removed
environment
Working temp,humidity
-10°C~+60°C,20%~90%RH
Storagetemp,humidity
-20°C~+85°C,10%~95%RH non-condensing
Withstand vibration
10~500HZ,2G 10min/1cycle,period for 60 minutes,
each axes
safety
Withstand voltage
I/P-O/P:2.0KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
Isolated resistance
I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC
Application:
-
Indoor LED illuminating lights
-
LED Neon, LED urban Decoration
-
LED Lighting Advertising,LED Display
-
Safety Protection Apparatus,
-
Telecommunications, Networks
-
Vehicle Lights, Controller Panels
Packaging & Shipping
Packing
N.W./pcs
G.W/ctn
Qty/ctn
Carton Size( m³)
12v 60w enclosure power supply
500g/pcs
13.5kg/ctn
30pcs
0.0318 m³
Packing:
Company Information
Quanzhou Smarts Electronic & Technology Co.,Ltd (SMARTS INDUSTRIAL (HOLDING) CO LTD) was founded in 1998. The company is located in a developed economy, abundant resources, beautiful scenery of Quanzhou city Licheng district town pontoon, the company has an area of 2000 square meters, production workshop, warehouse, office, living facilities complete with. With the development of society, human increasing awareness of "green energy, environmental protection, save energy" becomes...View this Supplier's Website
Model | SMT-005-060SA | SMT-012-060SA | SMT-024-060SA | SMT-036-060SA | ||
output | DC voltage | 5V | 12V | 24V | 36V | |
Voltage tolerance | ±2% | ±1% | ±1% | ±1% | ||
Rated current | 12A | 5A | 2.5A | 1.67A | ||
Current range | 0~12A | 0~5A | 0~2.5A | 0~1.67A | ||
Rated power | 60W | 60W | 60W | 60W | ||
Ripple&noise | 100mvp-p | 150mvp-p | 150mvp-p | 150mvp-p | ||
DCvoltage ADJ.range | ± 10% | ±10% | ±10% | ±10% | ||
input | Voltage range | 100~240Vdc | ||||
frequency | 47~63HZ | |||||
AC current | 3.2A/115VAC,1.6A/230VAC | |||||
efficiency | 83% | 83% | 83% | 83% | ||
Inrush current | Cold start current 18A/115VAC,36A/230VAC | |||||
Leakage current | < 1mA/240VAC | |||||
protection | overload |
Rated output power115%~150% start over load protection |
||||
protection type:cutoff output,recovery after restart power |
||||||
Over voltage | 6.8~8.2V | 15.6~17.8V | 18.6~20.8V | 30.6~33.2V |
|
|
protection type:hiccup mode,auto-recovery after fault condition is removed |
||||||
environment | Working temp,humidity | -10°C~+60°C,20%~90%RH | ||||
Storagetemp,humidity | -20°C~+85°C,10%~95%RH non-condensing | |||||
Withstand vibration |
10~500HZ,2G 10min/1cycle,period for 60 minutes, each axes |
|||||
safety | Withstand voltage | I/P-O/P:2.0KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC | ||||
Isolated resistance | I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC |
Application:
- Indoor LED illuminating lights
- LED Neon, LED urban Decoration
- LED Lighting Advertising,LED Display
- Safety Protection Apparatus,
- Telecommunications, Networks
- Vehicle Lights, Controller Panels
Packing | |||||||
N.W./pcs | G.W/ctn | Qty/ctn | Carton Size( m³) | ||||
12v 60w enclosure power supply | |||||||
500g/pcs | 13.5kg/ctn | 30pcs | 0.0318 m³ | ||||
