SPECIFICAION
MODEL
SMT-012-060VW
SMT-024-060VW
SMT-036-060VW
OUTPUT
DC VOLTAGE
12V
24V
36V
RATED CURRENT
5.0A
2.5A
1.66A
CURRENT RANGE
0~5.0A
0~2.5A
0~1.66A
RATED POWER
60W
60W
60W
RIPPLE&NOISE(max)
1.2V
1.2V
1.2V
voltage TOLERANCE
12V±5%
24V±5%
36V±5%
SETUP RISE TIME
80ms/110,220VAC
80ms/110,220VAC
80ms/110,220VAC
HOLD UP TIME(Typ.)
60ms/110,220VAC
60ms/110,220VAC
60ms/110,220VAC
INPUT
VOLTAGE RANGE
90~135/170~265Vac
90~135/170~265Vac
90~135/170~265Vac
FREQUENCY RANGE
50~60Hz
50~60Hz
50~60Hz
POWER FACTOR(Typ.)
EFFICIENCY(Typ.)
﹥84%
﹥84%
﹥84%
AC CURRENT(Typ.)
0.5A/110V,220VAC
0.5A/110V,220VAC
0.5A/110V,220VAC
INRUSH CURRENT (Typ.)
COLD START 30A/110,220VAC
PROTECTION
Short circuit
Protection type:recovers automatically after condition is removed
Overload
overload protected@145-160% above peak rating
Over temperature
Protection type:Shut down o/p voltage,re-power on to removed
ENVIRONMENT
WORKING TEMP.
-30~+50℃ (Refer to output load derating curve)
WORKING HUMIDITY
20~99% RH non-condensing(Waterproof)
STORAGE TEMP.,HUMIDITY
-40~+80℃,10~99%RH
SAFETY&EMC
SAFETY STANDARDS
UL, CE Mark(LVD),IP67
WITHSTAND VOLTAGE
I/P-O/P:1.5KVAC IP-GND:1.5KVAC
EMC Test Standards
EN55015:2006;EN61547:1995+2000;EN61000-3-2:2006
EN61000-3-3:1995+A2:2005;EN61346-1:2001;EN61347-2-13:2006
NOTE
1.All parameters NOT specially mentoned are measured at 110VAC, 220VAC input,rated load and 25℃ of ambient temperature.
2.Ripple&noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf&10uf parallel
3.Tolerance:includes set up tolerance,line regulation and load regulation.
Label
Specifications
Features
Environment
Safety
* Isolation Resistance : I/P-O/P:100M Ohms/500VDC
Applications
* Vehicle Lights Controller Panels,etc.
