Troubleshooting for your led electronic driver May 23, 2019
Some of our clients will meet some installation problems when they install our Dimmable LED Power Supply. What you should check first when there have issues for your 12 Volt Led Electronic Driver? Pls. review following items:

1. Fixture does not illuminate
--Ensure the system is wired correctly and polarities are correct.
--Ensure a compatible constant voltage dimmable fixture is installed.
--Ensure the driver and fixture have the same
--voltage specifications (12V & 12V, or 24V & 24V).

2. Fixture is quickly flashing or flickering
--Verify a compatible dimming control is installed. If flickering is apparent at low light levels install a compatible trim-adjustable dimming control.
--Ensure a compatible constant voltage dimmable fixture is installed.
--Ensure different fixture types are not connected to a single driver. Different fixture types must be connected to individual drivers.
--Ensure all connections are properly secured.
--Ensure fixture is receiving the correct input voltage

3. Fixture is slowly flashing
--Ensure driver is not overloaded. An overloaded Triac Dimmable Led Driver will cause the internal auto-reset to trip repeatedly

4. Installation Trips Main Breaker
Check wiring for short circuit. If breaker continues to trip there may be a short in the driver.

5. Fixture does not dim
--Ensure a compatible constant voltage dimmable fixture is installed.
--Ensure a compatible dimming control is installed and wired correctly.

6. Different fixture types do not dim in sync
-- Different fixture types have different circuit designs and may react differently when dimmed. Ensure each fixture type is installed on a separate driver for best performance.

If you have checked all above items but problems still exist, pls. contact with Mr. Steven(skype: steven821228 mail:steven@smartselectronic.com.cn) .
