12v 6w triac dimmable led driver
Specifications
AC-DC Triac Dimmable LED Driver
I/P:90~135V/ 170~265V, 47~63Hz
Ambient temp.:-20 degree~40 degree @ full load
Efficiency > 86%
PF>0.9
size:140*45*28 mm
waterproof rate: IP40
packing: 50pcs/ctn
Environment paramete
Working temperature:-40 -80°C
Store temperature:-40 -85°C
Working humidity:10-90%
Lifespan:(MTBF)50,000 hours
Case machine specifications
Case: plastic case
Product Features
1.Universal AC input (90-135V/170-265V) / Full range
2.Protections: Short circuit/Overload/Over voltage/Over temp.
3.Built-in active PFC function
4.PF>0.92 for 86% of load or higher
6.Cooling by nature
7.Suitable for dry location
8.Suitable for LED lighting and moving sign applications
9.Follow the global lighting safety regulations
Safety
Safety Standards : IEC 61347 –2–11 , IEC 61347 –1 , IEC 60529
Withstand Voltage : I/P-O/P: 3000KVAC
Isolation Resistance : I/P-O/P:100M Ohms/500VDC
Product parameters
| Traic dimmable constant voltage LED driver/power supply |
| Model No. | Input voltage (vAC) | Working frequency | Output voltage (vDC) | Output current | Power | Working Temp. | IP rate |
| SMT-012-006VT | 90-135V/170-265 vAC | 47-63Hz | 12v | 0.5A | 6w | -25~50°C | IP40 |
| SMT-024-006VT | 90-135V/170-265vAC | 47-63Hz | 24V | 0.25A | 6w | -25~50°C |
IP40
|
 |
 |
 |
 |
Application
Our products are widely used in various industries, such as outdoor LED illuminating lights, LED Neon, LED City Decoration, LED Lighting Advertising, LED Display, Safety Protection Apparatus, Telecommunications, Networks, Vehicle Lights, Controller Panels, etc.
